Alloy:6061
Width: 500mm - 2300mm
Thickness: 0.2mm - 350mm
Port of Loading: Qingdao
Certificated: ISO9001:2015 and AS9100
6061 aircraft aluminum is an extremely versatile heat treatable aluminum alloy due to its content of silicon and magnesium. 6061 has a wide range of mechanical and corrosion resistance properties as well as having most of the good qualities of aluminum. 6061 is used in a many applications from aircraft structures to screw machine parts.
Aluminum and its alloys are divided into two general classes – casting alloys and wrought alloys. Casting alloys are those that can be cast in sand, or poured into molds to give them a shape. The wrought alloys, which include the 6061 aluminum alloy, are cast and then hand-worked by extruding, rolling or forging them into the desired shapes. Some of these alloys can be heat-treated by different methods to increase their strength and hardness.
6061 aluminum properties include its structural strength and toughness, its good surface finish, its good corrosion resistance to atmosphere and sea water, its machinability, and its ability to be easily welded and joined. Most other aluminum alloys are difficult to weld due to their chemical composition and lack of conductivity. While welded 6061 aluminum alloy materials may lose some strength, they can be re-heat-treated and artificially aged again to restore strength, making this one of the superior alloys.
Technical Data Sheet of 6061 aircraft aluminum
Chemical Composition Limits | |||||||||||
Weight% | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other Each | Others Total |
6061 | Bal | 0.40 - 0.80 | 0.70 max | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
Typical Mechanical Properties of 6061 aircraft grade aluminum
Material | Thickness (in | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation |
Alloy 6061 Sheet T6 | 0.020-0.500 | 42 | 35 | 10 |
Alloy 6061 Sheet T6 | 0.500-1.000 | 42 | 35 | 9 |
Alloy 6061 Sheet T6 | 1.00-2.00 | 42 | 35 | 8 |
Alloy 6061 Sheet T6 | 2.00-4.00 | 42 | 35 | 6 |
Alloy 6061 Sheet T6 | 4.00-6.00 | 40 | 35 | 6 |
Material | Temper | Diameter (in) | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation |
Alloy 6061 Bar Cold Finished | T6511 | <0.25" | 38 | 35 | 8 |
Alloy 6061 Bar Cold Finished | T6511 | >0.25" | 38 | 35 | 10 |
Alloy 6061 Bar - T651 / T6 condition and extruded T6511/T6 | |||||
Alloy 6xxx series as cold-treated forging material meets the needs of products that have strict requirements on corrosion resistance and high oxidation. The 6xxx series alloy equips with many outstanding characteristics like fine usability, smooth connector, easily coating and perfect processability. The 6xxx series alloy are suitable for the accessory parts on the low-pressure weapons and aircraft joints.
Specifications of 6xxx series alloy applied on the aerospace:
Alloy |
| ||||||||
Fe | Si | Cu | Mn | Mg | Zn | Cr | Ti | Al | |
6005 | 0.35 | 0.6-0.9 | 0.1 | 0.1 | 0.4-0.6 | 0.1 | 0.1 | 0.1 | Remain |
6061 | 0.7 | 0.4-0.8 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.25 | 0.04-0.35 | 0.15 | Remain |
6063 | 0.35 | 0.2-0.6 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | Remain |
6082 | 0.5 | 0.7-1.3 | 0.1 | 0.40-1.0 | 0.6-1.2 | 0.2 | 0.25 | 0.1 | Remain |
Typical features and applications of regular alloy 6xxx series:
Alloy | Features | Applications |
6061/6063 | Processed with heat treatment pre stretching, strength not good as 2024 and 7075 but 6061 has very good formability,welding quality and anti-rust quality, 6061 does not become deformed after shaping and it has good quality for polishing, anodizing and color film. | Airplane, rocket forged ring;transportation device such as subway train, vehicle, parts for engineer;packing such as can use thin coil of 6061,; PS plate for printing; construction and decoration using good welding and surface treatment quality of 6061; home appliance parts such as electric devices etc |
6082 | Medium strength and good welding quality and anti-rust quality. | For transportation and construction project like high-speed boat, heavy-lift, roofing structure etc |
6061 Aluminum Uses:
6061 aluminum is used extensively as a construction material, most commonly in the manufacture of automotive components. The 6061 alloy is well-suited to the construction of yachts, motorcycles, bicycle frames, scuba tanks, camera lenses, fishing reels, electrical fittings, couplings and valves. It's used in the construction of aluminum cans, and the inside foil wrapper on food containers is often made with 6061 aluminum alloy. Aluminum-magnesium-silicon alloys are also used in wide-span roof structures for bridge decks and arenas.
